| Type of Product: |
Heater assembly |
| Manufacturer: |
LX |
| Power: |
Volts: 240vac Hz: 50/60 KW: 3.0 Amps: 13.4 |
| Specifications: |
Sensor compatibility: Sensor built in the heater is controlled by a thermoregulator on the side of the module.Material spec: PlasticRequired flow rate: Set by the pressure switch this switch will need to be pressurised if it runs straight to a big bore outlet with no bends there will be no back pressure and it may not work. Pressure switch operated by an extra cord. |
| Compatible With: |
Most Chinese spas with a small plumbing change or can be used as a remote heater on a bespoke project |
| Connections & Fixings: |
1.5" white plastic female sockets to connect to plumbing |
| Dimensions: |
Length: 170mm Diameter: 50 mm Between terminals: 120 mm Overall length complete: 340 mm |
| Additional Notes: |
High-limit thermal cutout built in. This unit is rated IPX5 and has CE approval. |
