Balboa JZ6013X2 (Jazzi) Controller 3.0Kw

B-56761

Aquarius Spa Parts

Regular price $1,500.00

Tax included.

Touchpad sold separately.

JZ6013X2 240volt Output Sockets
CPUMP: Circ pump (must have a circ pump if pump 1 single speed)
PUMP 1: 1Spd Pump or 2Spd Pump
PUMP 2: 1Spd Pump
PUMP 3: 1Spd Pump
PUMP 4: 1Spd Pump
BLOWER: Blower
240V: This outlet has a constant 240volts and is not switchable
O3/UV: This outlet is only to be used with an ozone system

JZ6013X2 Low Voltage
2 x Touchpad Outlets
1 x AUX Outlet
1 x Light
1 x Wifi Port

JZ6013X2 Features
*In heater temp sensors
*Max Temp 40 degrees
*Adjustable Filtration
*Heater Modes (Ready & Rest)
*Wifi Interface
*Programmable Load Shedding



Controller Specifications
Heater Wattage: 3000w
Max Current: 32amp
Power Lead: Hard Wired
Power Lead Length: N/A
Heater Unions: 50mm

Controller Dimensions
Length: 382mm
Height: 300mm
Width: 110mm
Weight: 3.8kg
