Aqua-flo XP2e Wet End 1.5HP* 56f (6.1" Euro Legs) Wet End Assembly (2x2)

PW-AF525

Aquarius Spa Parts

Price on application

Tax included.
Type of Product: Wet end assembly
Manufacturer: Gecko / Aqua-flo
Connections: 2 inch Waterway or Aqua-flo unions. Both suction and pressure have a flat smooth connection meaning that the o'ring would be attached to the union sleeve. The wet end fixes to the pump body with 4 x small bolts this part holds the female receptacle part of this attachment. The impeller is screwed on to the shaft which protrudes from the centre of the pump body.
Dimensions: Length: 200 mmWidth: 185 mm (main face diameter not screw holes)Depth: 140 mm
Commonly Used With :
Additional Notes:

Fits the older smooth body Emerson 56 frame (6.1") pumps only. There is an identical part to this that was used with Magnetek motors which was 56 frame (6.3")

This unit includes the housing the face plate the face plate o-ring the 2.5hp impeller and the ceramic seal kit. This unit also includes a built in bleed screw.

The space between the impeller plates is 10mm
